RAVENOL UTTO CVT Fluid is a combined transmission and hydraulic oil for agricultural, forestry and construction machinery. It is a special developed universal oil which can be used in combined hydraulic and transmission systems as well as in wet brakes in modern machines. High quality base oils and selected additives guarantee trouble-free operation of all aggregates at at any seasons.
RAVENOL UTTO CVT Fluid offers a wide range of applications as it meets a large number of specifications.
Application Note
RAVENOL UTTO CVT Fluid was specially developed for use in CVT transmissions and therefore offers optimized friction behavior and maximum wear protection.
RAVENOL UTTO CVT Fluid is suitable for wet brakes in powershift clutches and auxiliary drives.The product is not suitable as an engine oil.
Characteristics
- a very high stable viscosity index for year-round use
- a very low pour point
- a high oxidation stability
- protection against corrosion and wear
- a convenient coefficient of friction during running brakes in oil bath (wet brakes) of load changecouplings and minor drives
- zincfree formulation
- very good water tolerance in the hydraulic and transmission circuit
Мүнөздөмөлөр
| Параметр | Маани | Аудит |
|---|---|---|
| Щелочтук саны, mgKOH/g | 2.38 | ASTM D2896 |
| Сульфаттуу күлдүүлүк, %wt. | 0.3 | DIN 51575 |
| NOACK боюнча учуучулук, % | 8 | ASTM D5800 |
| Көбүк пайда болуу мүмкүнчүлүгү (Seq. I, II, III) | --- | --- |
| Brand | RAVENOL | |
| Туура келет | Argo VT-DRIVE, Case ICH CVXDrive, Fendt Vario CVT Transmissions, New Holland CVT | |
| Продукттарга шайкеш келет | Sauer Sunstrand/ Danfoss (hydrostatic trans fluid) | |
| Көбүк пайда болуу І – 24°Cде, ml/ml | 10/0 | ASTM D892 |
| Көбүк пайда болуу II – 93.5°Cде, ml/ml | 20/0 | ASTM D892 |
| Көбүк пайда болуу III – 24°Cден 93.5°Cге чейин, ml/ml | 10/0 | ASTM D892 |
| Илешкектүүлүк 100°Cде, mm²/s | 9.3 | DIN 51562-1 |
| Илешкектүүлүк 40°Cде, mm²/s | 56.4 | DIN 51562-1 |
| Илешкектүүлүк индекси VI | 147 | DIN ISO 2909 |
| Төрт шариктүү трение машинасы тестинде эскирүү, mm | 0.5 | DIN EN ISO 20623 |
| Тығыздык 20°Cде, g/cm³ | 863.3 | EN ISO 12185 |
| Жануу температурасы, °C | 230 | DIN EN ISO 2592 |
| Муздоо температурасы, °C | -42 | DIN ISO 3016 |
